Product Name: IP65 180x3W LED City Color
Product status: conventional product (originated in Guangzhou-China)
Place of Origin: China (Guangzhou)
Product model: LY-1805W waterproof 180pcs LED city lights
Product power: AC220V/110V, 50/60Hz
Obtained certification: CE, ROHS, quality inspection report
Product packaging: carton (air box optional)
Brand Name: LY Lingyue Optoelectronics
Production method: OEM, ODM, OBM

Scan to add WeChat customer service to provide more comprehensive services

Parameter

Lighting Effect

Video Show

Applications

Download

Model: LY-1805W

Name: Waterproof 180pcs LED city lights

1. Power supply, optical system
Rated voltage	AC90V-240V±10%,50-60Hz	rated power	600W
Translucent lens	Frosted lens (or lens with smooth surface)	Lens angle	25°（15°/45°/60°）
LED lamp bead specifications	180pcs 3W high brightness LED	control panel	LED LCD display + button

2. Color/Life/Environment
colour	Red, green and blue in one, unlimited color mixing	working environment	temperature：-20-40℃ humidity：5%-95%
LED lamp life	6-10 million hours	Chip current	600mA

3. Functional effect
Control mode	Self-propelled/master-slave/DMX512/voice control	Dimming	0%～100% linear dimming
aisle	8 DMX512 channels (digital display)	Strobe	1-30 times/second electronic strobe and random strobe

4. Appearance and packaging
Material	Die-cast aluminum alloy split heat dissipation structure design	Lamp net weight	29.9kgs
1 unit/wooden box gross weight	28kgs	1 set / wooden box size	50x75x54cm
2 units/air case gross weight	51kgs	2 units/flight box size	67x71x45cm

5. Other
Installation method	Fixed to the ground with screws	waterproof level	IP65
Standard accessories	Aluminum lamp hook + lamp comes with signal line and power line + instruction manual	Certification and reporting	CE/ROHS/ISO9001/Quality inspection report/IP65 waterproof grade inspection report
Custom requirements	Customization is not supported for less than 30 units, and the delivery time for customized models will increase, about 10 days (customization such as: LED light source / silk screen LOGO / packaging / LED lens angle, etc.)	Scope of application	Bridge/park/TV tower/ferris wheel/nightclub/party/hotel wedding/outdoor large-scale commercial performance, etc.
