Product parameters:

Rated Voltage: AC100V~240V ±10﹪, 50Hz～60Hz

Total Power: 650W

Bulb: Yodn/Osram/Philips 440W (2000 hours)

Optical Lens: 6 lens lens group

Rotation Angle: 540° in the horizontal direction, 270° in the vertical direction (16bit precision scanning)

Beam Angle: 2.5°-20°

Control Mode: self-propelled, master-slave, DMX512, voice control

Channel Mode: 18 international standard DMX512 channels

Electronic Focus: high-precision glass optical lens, 50000LUX at 20 meters

Strobe: Strobe speed is 1-20 times per second, pulse strobe, synchronous and asynchronous strobe.

Dimming: 0%-100% linear dimming

Atomization: 0%-100% linear atomization, 1 independent atomization effect

Gobo Plate: 1 fixed gobo plate has 17 gobos + white circle, with pattern jitter and pattern arbitrary positioning function, 1 rotating gobo plate can choose 9 glass patterns or customized LOGO or one glass pattern can be replaced with a colorful plate effect

Color Wheel: 1 fixed color wheel has 13 color chips, can be half-color effect, linear color conversion and two-way variable speed rotation rainbow effect

Prism Disk: double prism effect, can be superimposed, 8/16/24 prism or waffle prism (8+8+8 or 8+16+24 optional) can be rotated forward and backward, and has prism positioning function, prism atomization Features

Focusing: with linear focusing function, 2 meters to infinitely adjustable pattern definition.

Display: LCD liquid crystal display + buttons or touch screen

Waterproof rating: IP20

Product Size: 38.2x36.5x58.7cm Lamp net weight: 15kgs

1pc/carton packing size: 47x47x74cm gross weight: 23kgs

2pcs/flycase packing size: 83x44x84cm gross weight: 72kgs
